Vector Optics Owlset HEIM ES X-Nano XPD Mini Thermal Sight Wi-Fi VEOT-RSS08

Owlset HEIM ES X-NANO Mini Thermal Sight Wi‑Fi overview

• Light, compact body at 123 g (4.34 oz) suitable for pistol and AR‑15 platforms
• 256×192 thermal imaging with 12 μm sensor, 50 Hz refresh, 19 mm lens, and 1.4" touchscreen display
• Built‑in Wi‑Fi with on‑device menu control
• IP66 waterproof rating and 1000 G shock resistance
• Six selectable pseudo‑color modes and 10 reticle options with color modes
• Battery: 16280, 900 mAh (not included); operating duration up to 3.5 hours

Specification highlights

• Infrared Resolution: 256×192 / 12 μm
• Frame Rate: 50 Hz
• Basic Magnification: 0.5x
• Digital Zoom: 1x / 2x
• NETD: ≤40 mK
• Detection Range: up to 600 m
• Recognition Range: up to 150 m
• Weight: 123 g / 4.34 oz
• Waterproof: IP66
• Shockproof: 1000 G
• Battery Type (Not Included): 16280, 900 mAh
• Operating Duration: 3.5 h
• Charging Interface: USB Type-C, 5 V
• Operating Temperature: -20°C to 60°C
• Items in the Package: Mounting Base, Plastic Wrench, Torx Wrench, USB Charging Cable, Dual-Slot Battery Charger, Batteries*3

Size and visuals

• Size: 51×43×46 mm (2.01 x 1.69 x 1.81 in)
• Images show the Owlset HEIM ES X-NANO in multiple angles

Notes

• This product is an optic sight compatible with pistol and AR-15 platforms and includes Wi‑Fi connectivity for control and status information.
